32 Inch 4K UHD LCD Digital Signage Touch Display 1920*1080 Resolution CCC Certified

32 Inch 4K UHD LCD Digital Signage Touch Display 1920*1080 Resolution CCC Certified

Brand Name:	YOULESHI
MOQ:	1
Payment Terms:	T/T
Supply Ability:	Monthly supply of 2000 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

SHENZHEN

Certification:

CCC,RoHS,FCC,CE

Packaging Details:

Paper box/wooden box/flying box

Highlight:

Digital Signage Touch Display 1920*1080

LCD Digital Signage 1920*1080

CCC certified LCD Digital Signage

Product Description

32 Inch K-Base IR Touch Screen

This retail-ready 32-inch touch screen features a stable K-shaped base design with precise infrared touch technology. The 4K UHD display delivers exceptional clarity, making it perfect for high-traffic retail environments, promotions, and interactive customer displays.

Product Specifications

Display Features

Display Screen	TFT-LED
Size	32 Inch
Screen Proportions	16:9
Effective Display Area	698mm * 392.45mm
Resolution	1920 * 1080 (4K UHD)
Luminance	300 cd/m²
Contrast Ratio	1200:1
Display Colors	1.06B (10-bit)
Viewing Angle	178°/178° (H/V)
Response Time	6ms
Video Features	3D digital comb filter, 3D image motion noise reduction, 3D motion adaptive comb filter

Hardware Configuration

Android Model: ULS-32AC01

Windows Model: ULS-32DC01

CPU: RK3566 quad-core 1.8GHz
Internal Storage: 2G
Built-in Memory: 32G
Decoding Resolution: 1080P
Operating System: Android 11.0
Network Support: Ethernet, WiFi, 4G (optional)
Audio Output: Stereo audio output
Network Interface: RJ45
Ports: 2*USB, 1*HDMI OUT, 1*TF, 1*AUDIO, 1*LAN, 1*DC 12V
Video Playback: H.264 MKV, WMV9, MPEG 1/2/4, HD Divx, Xvid, RM/RMVB
Audio Playback: MP3, WMA, WAV, EAAC+, MP2, Vorbis (Ogg), AC3, FLAC, APE, BSAC
Image Playback: BMP, PNG, GIF, JPEG
System Upgrade: Support USB/T card

CPU: i3/i5/i7 (optional)
Frequency: 1.8/2.0GHz
Memory: 4G/8G/16G/32G/64G
Hard Disk: 128G/256G/512G SSD
I/O Interface: 4*USB, 1*RJ45, 1*Audio output/input, 1*HDMI output, 1*VGA output
Supported Systems: WIN7/WIN10/WIN11
BIOS: AMI BIOS, ACPI supported, Support power on function
Menu Language: Chinese/English
Video: H.264 MKV, WMV9, MPEG 1/2/4, HD Divx, Xvid, RM/RMVB
Audio: MP3, WMA, AAC
Picture Format: BMP/PNG/JPEG
Additional Features: Multi-point function supports zooming, rotating, and moving multimedia content. Supports automatic shutdown, one-click power on/off, sleep timer, HDCP support

Infrared Touch Characteristics

Transmittance	100%
Installation Method	Embedded in aluminum profile frame
Sensing Technology	Infrared emitter with same wavelength detection
Sensing Objects	Finger, infrared pen
Response Time	3ms
Sensing Accuracy	±1.5mm
Touch Points	10-point multi-touch
Touch Life	More than 60 million times (no cursor drift)
Touch Resolution	4096 * 4096
Communication Mode	Infrared signal transmission
Operating Conditions	Not suitable for extremely strong light environments

Electrical Specifications

Power Switch	Premium industry-grade (10,000 cycles)
Speaker	2 * 5W (8Ω)
Audio Pattern	Stereo
Input Voltage	AC 100-240V 50/60Hz
Standby Power	Less than 1W (low power standby mode)
Power Rating	≤68W
Operating Temperature	-20℃ to +60℃
Operating Humidity	20% to 80%

Frequently Asked Questions

Are you a factory or a trading company? What is the minimum order quantity?

Yes, we are a factory direct sales company. We have some stock available, and you can place an order for 1 unit for testing purposes.

Where are your products used?

Our products are widely used in hospitals, schools, offices, conference rooms, shopping malls, airports, high-speed rail stations, parks, scenic areas, banks, office buildings, government halls, etc.

What are the main products you manufacture?

We specialize in manufacturing display products including Indoor/Outdoor Digital Signage, Touch Information Screens, Conference/Teaching Interactive Tablets, LCD Video Walls, Industrial LCD Displays, Bar Screens, LCD Transparent Display Cabinet, OLED Transparent Screens, Portable Display Screen, LED Displays, LED Poster Screen, LED Transparent Screen, Holographic 3D Displays, 360 Degree Photo Booths, Live Streaming All-In-One Machines, AI Human Recognition Displays, Curved Displays, and Customized Designs.

What is the delivery time? Where do you ship from?

Generally, small orders can be shipped within 5-7 days, while production time for orders of 10 units or more is around 15 days. Our factory is located in Guangming District, Shenzhen. If you have a freight forwarder in Shenzhen, we can arrange shipment to your freight forwarder.

Do you provide OEM and ODM services?

Yes, we offer OEM and ODM services, including software customization, packaging design, product labeling, etc. For more details, please consult our customer service.

What is the warranty period for your products?

Typically, our products come with a 1-year warranty. We have a professional after-sales service team. For specific details, please contact our customer service.

How do you ensure product quality?

All our products undergo strict QC inspections during the production process. Especially for export products, they go through a 72-hour aging test to ensure they are problem-free before shipment.

How do you arrange transportation?

For small sample orders, we recommend express delivery (7-10 days) or air freight (10-15 days). For bulk production, sea freight is more cost-effective. Please consult our customer service for more details!
