55" 4K UHD LCD IR Touch Screen With Commercial Grade K Shaped Base Anti Scratch Surface

55" 4K UHD LCD IR Touch Screen With Commercial Grade K Shaped Base Anti Scratch Surface

Brand Name:	YOULESHI
MOQ:	1
Payment Terms:	T/T
Supply Ability:	Monthly supply of 2000 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

SHENZHEN

Certification:

CCC,RoHS,FCC,CE

Packaging Details:

Paper box/wooden box/flying box

Highlight:

Anti Scratch IR Touch Screen

K Shaped Base IR Touch Screen

Anti Scratch LCD Touch Screen

Product Description

55” 4K Commercial-Grade K-Shaped Base LCD IR Touch Screen

This 55" 4K UHD commercial display features a durable K-shaped base construction with anti-scratch protection and low power consumption. Designed specifically for high-traffic mall environments, it delivers engaging visual experiences while maintaining operational efficiency.

Display Specifications

Display Screen	TFT-LED
Size	55 Inch
Screen Proportions	16:9
Effective Display Area	1209.2mm × 680mm
Resolution	3840 × 2160
Luminance	300cd/m²
Contrast Ratio	1200:1
Display Colors	1.06B (10bit)
Viewing Angle	178°/178° (H/V)
Response Time	6ms
Video Features	3D digital comb filter, 3D image motion noise reduction, 3D motion adaptive comb filter

Hardware Configuration

Android Model: ULS-55AC01

CPU: RK3566 quad-core 1.8GHz

Internal Storage: 2GB

Built-in Memory: 32GB

Decoding Resolution: 4K

Operating System: Android 11.0

Network Support: Ethernet, WiFi, 4G (optional)

Audio Output: Stereo audio output

Network Interface: RJ45

I/O Ports: 2×USB, 1×HDMI OUT, 1×TF, 1×AUDIO, 1×LAN, 1×DC 12V

Video Playback: H.264 MKV, WMV9, MPEG 1/2/4, HD Divx, Xvid, RM/RMVB

Audio Playback: MP3, WMA, WAV, EAAC+, MP2 dec, Vorbis (Ogg), AC3, FLAC, APE

Image Formats: BMP, PNG, GIF, JPEG

System Upgrade: Support USB/T card

Windows Model: ULS-55DC01

CPU: i3/i5/i7 (optional)

Clock Speed: 1.8/2.0GHz

Memory: 4GB/8GB/16GB/32GB/64GB

Hard Disk: 128GB/256GB/512GB SSD

I/O Interface: 4×USB, 1×RJ45, 1×Audio output/input, 1×HDMI output, 1×VGA output

Supported Systems: WIN7/WIN10/WIN11

BIOS: AMI BIOS, ACPI supported, Power on function for incoming calls

Menu Language: Chinese/English

Video: H.264 MKV, WMV9, MPEG 1/2/4, HD Divx, Xvid, RM/RMVB

Audio: MP3, WMA, AAC

Picture Format: BMP, PNG, JPEG

Additional Features: Multi-touch functionality, automatic shutdown, one-click power on/off, sleep timer, HDCP support

Infrared Touch Characteristics

Transmittance: 100%

Installation: Embedded in aluminum profile frame

Induction Technology: Infrared emitter with same wavelength detection

Sensing Objects: Finger, infrared pen

Response Time: 3ms

Accuracy: ±1.5mm

Touch Points: 20-point touch

Touch Life: 60+ million touches

Resolution: 4096×4096

Communication: Infrared signal transmission

Light Sensitivity: Not suitable for extremely bright environments

Electrical & Environmental Specifications

Power Switch: Premium industry-grade (10,000+ cycles)

Speakers: 2×5W (8Ω)

Audio Pattern: Stereo

Input Voltage: AC100-240V 50/60Hz

Standby Power: <1W

Rated Power: ≤118W

Operating Temperature: -20℃ to +60℃

Operating Humidity: 20% to 80%

Cabinet Structure & Design

Design: Safe rounded corners, aluminum alloy frame

Construction: High-quality sheet metal with 5-year protection

Glass: AR double tempered glass (80+ MPA impact resistance)

Surface Finish: Sandblasted oxidation, silver frame, white with black silkscreen

Corner Design: Rounded corners

Frequently Asked Questions

Are you a factory or a trading company? What is the minimum order quantity?

Yes, we are a factory direct sales company. We have some stock available, and you can place an order for 1 unit for testing purposes.

Where are your products used?

Our products are widely used in hospitals, schools, offices, conference rooms, shopping malls, airports, high-speed rail stations, parks, scenic areas, banks, office buildings, government halls, etc.

What are the main products you manufacture?

We specialize in manufacturing display products such as Indoor/Outdoor Digital Signage, Touch Information Screens, Conference/Teaching Interactive Tablets, LCD Video Walls, Industrial LCD Displays, Bar Screens, LCD Transparent Display Cabinet, OLED Transparent Screens, Portable Display Screen, LED Displays, LED Poster Screen, LED Transparent Screen, Holographic 3D Displays, 360 Degree Photo Booths, Live Streaming All-In-One Machines, AI Human Recognition Displays, Curved Displays, Customized Designs, etc.

What is the delivery time? Where do you ship from?

Generally, small orders can be shipped within 5-7 days, while production time for orders of 10 units or more is around 15 days. Our factory is located in Guangming District, Shenzhen. If you have a freight forwarder in Shenzhen, we can arrange shipment to your freight forwarder.

Do you provide OEM and ODM services?

Yes, we offer OEM and ODM services, including software customization, packaging design, product labeling, etc. For more details, please consult our customer service.

What is the warranty period for your products?

Typically, our products come with a 1-year warranty. We have a professional after-sales service team. For specific details, please contact our customer service.

How do you ensure product quality?

All our products undergo strict QC inspections during the production process. Especially for export products, they go through a 72-hour aging test to ensure they are problem-free before shipment.

How do you arrange transportation?

For small sample orders, we recommend express delivery (7-10 days) or air freight (10-15 days). For bulk production, sea freight is more cost-effective. Please consult our customer service for more details!
