46.6 Inch Stretch Bar LCD Display Full Color With High Contrast Ratio

46.6 Inch Stretch Bar LCD Display Full Color With High Contrast Ratio

Brand Name: YOULESHI
Model Number: ULS-46TX02
MOQ: 1pcs
Supply Ability: 2000 pieces per month for each product
Detail Information
Certification:
CCC,RoHS,FCC,CE,UN38.3
Application:
Indoor
Type:
LCD
Color:
Full Color
Supplier Type:
ODM, Other, OEM
Media Available:
Datasheet, Photo
Place Of Origin:
Guangdong, China
Model Number:
ULS-46TX02
Brand Name:
YOULESHI
Use:
Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Exhibition Hall, Subway, Restaurant & Hotel Supplies, Education, Medical Treatment
Function:
SDK
Specification:
Stretch Bar
Touch Screen Type:
NO
Brightness:
500 Nits, 500 Nits
Response Time:
8ms, 8ms
Contrast Ratio:
3000:1, 3000:1
Lifespan (hours):
30000, 30000
IP Rating:
IP45, IP45
Installation Type:
Hanging, Hanging
Resolution:
158x2880
View Angle(H/V):
178(H)/178(V), 178(H)/178(V)
Warranty:
1-3Year
Size:
10.1 Inch-110 Inch
Resolution:
1920*1080/3840*2160
OS:
Android/Windows
Touch Screen:
Optional
4G:
Optional
Warranty:
1-3 Year
Life Time:
60000 Hours
Connectivity:
WiFi, Bluetooth
Panel:
100% A+ Grade Panel
Picture Format:
Mp3, Wma, Ogg, Aac, Wav
Color Option:
White/Black Or Optional
Certificates:
CE FCC ROHS
Usb:
Yes
Max Resolution:
1920*1080/3840*2160
Screen Size:
10.1-110 Inches
Operation Humidity Range:
10% To 80%
Osd Language:
English,Chinese
Contrast:
≥ 1000: 1
Input:
AC 110V~240V,50/60Hz, 110W
Touch:
Optional
Packaging Details:
Paper box/wooden box/flying box
Highlight:

46.6 Inch Stretch Bar LCD Display

,

Stretch Bar LCD Display Full Color

,

High Contrast bar lcd panel

Product Description
46.6 Inch Indoor Stretch Bar Display Screen

Industrial-grade LCD bar rack digital signage featuring edge display technology and wide panel LCD for professional advertising and information display applications.

46.6 Inch Stretch Bar LCD Display Full Color With High Contrast Ratio 0 46.6 Inch Stretch Bar LCD Display Full Color With High Contrast Ratio 1 46.6 Inch Stretch Bar LCD Display Full Color With High Contrast Ratio 2
Key Features
  • Automatic residual image removal function
  • High contrast (3000:1) and brightness (500 Nits) for vivid images
  • Fast 8ms response time with 178° ultra-wide viewing angle
  • Industrial-grade power supply with safety protections
  • Low energy consumption (27W max) with power outage protection
  • Customizable playback and power on/off scheduling
Technical Specifications
Panel Features
Active Display Area 1183.68(H) x 36.99mm(V)
Pixel Pitch 0.10275 (H) x 0.30825 (V) mm
Native Resolution 158x2880
Aspect Ratio 18:1
Brightness 500 Nits
Viewing Angle 178°(H)/178°(V)
Backlight LED (30,000+ hours lifespan)
System Specifications
OS Android 9.0
CPU ARM Cortex-A55 (1.9GHz)
Memory 2GB DDR RAM, 8GB EMMC Flash
Networking WiFi 802.11 b/g/n/ac (2.4G)
Supported Formats Video: AVI, H.264, MKV, MP4, MPEG
Image: JPG, JPEG, BMP, PNG, GIF
Audio: MP4, WAV, APE, FLAC, AAC
Power & Mechanical Specifications
Power Supply 100V-240V, 50-60Hz (12V 3A DC output)
Chassis Material Metal (Black)
Product Dimensions 1202.9 x 53.4 x 20.1mm
Weight Net: 1.2kg, Gross: 1.8kg
Accessories Warranty card, user manual, adapter, wall bracket
